Pressure Range: PN16~PN64, ANSI 150lb~ANSI 300lb, JIS 10K

Size Range: DN20 (3/4”)~DN300 (12”)

Flanged Ends: ANSI B16.5, API 605, BS 4504, DIN 2501, JIS B2220,  EN 1092-1, GB/T 9112, GB/T 17241.6, etc

Butt-Weld BW Ends: ANSI B16.25, BS 1640, DIN 3239, JIS B2312, EN 12627, GB/T 17185, GB/T 9113, etc

Temperature Range: -30℃~260℃

Valve Material

• Body Material WCB, WC6, WC9, CF8, CF8M, CF3, CF3M, etc
• Trim Material 304, 316, 316L, 2205, 2507, 2Cr13, 4Cr13, F11, F22, etc
• Spool And Seat Material 304, 316, 316L, 410, 20, 17-4PH, Monel, Hastelloy, etc
• Cage Material CF8, CF8M, etc
• Stem Material 304, 316, 316L, 420, 17-4PH, etc

Design Feature

• Trim Features sleeve-guided, balanced internal structure, with balance seal ring structure
• Body Type straight-through, angled
• Bonnet Form standard, heat sink, low temperature, bellows
• Flow Characteristics equal percentage, linear, quick opening

Inspection And Test

• Leakage Rating ANSI/FCI 70-2, API 598, BS 6364, DIN EN 12266, JIS B2003, EN 12266-1, GB/T 13927, JB/T 9092, etc
• Inspection And Testing Standard ANSI/FCI 70-2, API 598, BS EN 12266, DIN EN 12266, JIS B2003, EN 12266-1, GB/T 13927, JB/T 9092, etc
