Pressure Range: PN1.6MPa, 2.5MPa, 4.0MPa, ANSI 150lb~300lb

Size Range: DN6 (1/4”)~DN300 (12”)

Pressure Balance: stainless steel bellows

Flanged Ends: ANSI B16.5, API 605, BS 4504, DIN 2501, JIS B2220,  EN 1092-1, GB/T 9112, GB/T 17241.6, etc

Temperature Range: ≤120℃ (or 150℃)

Valve Material

• Body Material WCB, CF8, CF8M, etc
• Trim Material 304, 316, 316L, 2205, 2507, 2Cr13, 4Cr13, F11, F22, etc
• Plug Material austenitic stainless steel (metal seat), austenitic stainless steel'PTFE (soft seat)
• Bonnet Material WCB, CF8, CF8M, etc
• Seat Material 304, 316, 316L, 410, 20, 17-4PH, Monel, Hastelloy, etc
• Stem Material 304, 316, 316L, 420, 17-4PH, etc

Design Feature

• Spool Type single seat (P), double seat (N), sleeve (M)
• Flow Characteristics quick open

Inspection And Test

• Leakage Rating IEC60534: 1 bubble/min, 2 bubble/min, 3 bubble/min, 4 bubble/min, 6 bubble/min, 11 bubble/min
• Inspection And Testing Standard ANSI/FCI 70-2, API 598, BS EN 12266, DIN EN 12266, JIS B2003, EN 12266-1, GB/T 13927, JB/T 9092, etc
