Pressure Range: PN16~PN64, ANSI 150lb~ANSI 300lb, JIS 10K

Size Range: DN20 (3/4”)~DN300 (12”)

Flanged Ends: ANSI B16.5, API 605, BS 4504, DIN 2501, JIS B2220,  EN 1092-1, GB/T 9112, GB/T 17241.6, etc

Butt-Weld BW Ends: ANSI B16.25, BS 1640, DIN 3239, JIS B2312, EN 12627, GB/T 17185, GB/T 9113, etc

Temperature Range: -17℃~250℃

Valve Material

• Body Material CF8, CF8M, CF3M, etc
• Trim Material 304, 316, 316L, etc
• Spool And Seat Material 304, 316, 316L, etc
• Cage Material CF8, CF8M, etc
• Stem Material CF8, CF8M, CF3M, etc

Design Feature

• Trim Features top guided unbalanced Internals, quick release cage structure
• Body Type straight-through casting S type
• Spool Form single seat type, sleeve type, cage type
• Bonnet Form standard, heat sink, low temperature, bellows
• Gland Type bolt pressing type
• Flow Characteristics equal percentage, linear, quick opening
• Gland Packing V-type PTFE packing, impregnated PTFE asbestos packing, asbestos textile packing, graphite packing

Inspection And Test

• Leakage Rating ANSI/FCI 70-2, API 598, BS 6364, DIN EN 12266, JIS B2003, EN 12266-1, GB/T 13927, JB/T 9092, etc
• Inspection And Testing Standard ANSI/FCI 70-2, API 598, BS EN 12266, DIN EN 12266, JIS B2003, EN 12266-1, GB/T 13927, JB/T 9092, etc
