3 way electric control valve has two action types: electric mixing(converging) control valve and electric diverting(diverging) control valve.The 3 way electric control valve is composed of PSL series and 3810 series linear electric actuator and 3-way valve body.The electric actuator is an electronic integrated structure with a servo amplifier. The input control signal (4-20mADC or 1-5VDC) and the power supply can control the valve opening to achieve to control the parameters of pressure, flow, liquid level and temperature. The electric 3-way mixing control valve is mainly used for mixing two fluids into a third fluid; the 3 way diverging electric control valve is mainly used for dividing one fluid into two fluids.

Valve Material

• Body Material WCB, CF8, CF8M, CF3M, etc
• Gasket Material metal graphite gasket/PTFE
• Trim Material 304, 316, 316L, etc
• Spool And Seat Material 304, 316, 316L,  etc
• Bonnet Material WCB, CF8, CF8M, CF3M, etc
• Stem Material 304, 316, 316L,  etc

Design Feature

• Trim Features top guided unbalanced Internals, quick release cage structure
• Body Type straight-through, angled
• Spool Form single seat type, sleeve type, cage type
• Bonnet Form standard, heat sink, low temperature, bellows
• Gland Type bolt pressing type
• Flow Characteristics equal percentage, linear, quick opening
